项目Items |
规格Specifications |
||
|
型号 Model |
TPB-48200 |
||
|
电池类型 Battery Type |
磷酸铁锂LiFePO4 |
||
|
标称电压Nominal Voltage |
51.2V |
||
|
标称容量Nominal Capacity |
200Ah |
||
|
交流内阻Internal Impedance |
50≤mΩ |
||
|
标准充电电压Nominal Charge Voltage |
58.4±0.05 V |
||
|
放电截止电压 Discharge cut off Voltage |
40±0.5V |
||
|
最大充电电流 Max .Charge Current |
100A |
||
|
最大持续放电电流Max Continue .Discharge Current |
100A |
||
|
最大脉冲放电电流Max .Discharge pulse Current |
250A(2s) |
||
|
充电模式Charge method |
CC/CV(constant current/constant voltage) |
||
|
循环寿命Cycle life |
2000次循环后，容量大于典型容量的80% After 2000cycle,capacity more than 80% nominal capacity |
||
|
重量Weight |
＜160kg |
||
|
尺寸Size（L*W*H） |
740/840（L）mm*405（W）mm*570/620（H）mm |
||
|
工作温度Operating Temperature |
充电Charge: 0℃--45℃ 放电Discharge: -10℃--60℃ |
||
|
储存温度Storage Temperature |
5℃-35℃（建议在25±5℃ suggest 25±5℃） |
||
|
储存湿度Relative Humidity |
65±20% |
||
